MSI MAG B850 GAMING PLUS MAX WIFI
Specifications
VRM Design built with a total of 12+2+1 Digital
hipset : AMD B850
CPU :
Supports AMD Ryzen™ 9000/ 8000/ 7000 Series
Memory :
4x DDR5 UDIMM, Maximum Memory Capacity 256GB
Memory Support DDR5 8200
Onboard Graphics :
1x DisplayPort
Audio :
Realtek® ALC8977.1-Channel High Definition Audio
RAID :
Supports RAID 0 and RAID 1 for SATA storage devices
Supports RAID 0 and RAID 1 for M.2 NVMe storage devices
USB :
4x USB 2.0 (Rear)
4x USB 2.0 (Front)
1x USB 5Gbps Type A (Rear)
4x USB 5Gbps Type A (Front)
1x USB 10Gbps Type A (Rear)
2x USB 10Gbps Type C (Rear)
1x USB 10Gbps Type C (Front)
------------------------------
LAN :
 Realtek® 8126 5G LAN
WIRELESS LAN & BLUETOOTH
Wi-Fi 7 Solution
Supports Bluetooth® 5.4
------------------------------
Internal IO :
1x Power Connector(ATX_PWR)
2x Power Connector(CPU_PWR)
1x Power Connector(PCIE_PWR 8pin)
1x CPU Fan
1x Combo Fan (Pump_Sys Fan)
4x System Fan
1x EZ Conn-header (JAF_1)
2x Front Panel (JFP)
1x Chassis Intrusion (JCI)
1x Front Audio (JAUD)
1x Com Port (JCOM)
1x Tuning Controller connector(JDASH)
3x Addressable V2 RGB LED connector (JARGB_V2)
1x RGB LED connector(JRGB)
1x TPM pin header(Support TPM 2.0)
4x USB 2.0 ports
4x USB 5Gbps Type A ports
1x USB 10Gbps Type C ports
------------------------------
Product Number : MAG B850 GAMING PLUS MAX WIFI
Warranty Information
3 Years With Warranty of the Authorized Agent
